Waterproof 4k Flat 10 Meter HDMI Cable High Speed AWM 20276 For Multimedia

Waterproof 4k Flat 10 Meter HDMI Cable High Speed AWM 20276 For Multimedia

1.4 version hdmi cable

high performance hdmi cable

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

HDMI Connector

Contact Us
Request A Quote
Product Details
Quality:
100% QC Pass
Item:
Hdmi To Hdmi Cable
Length:
1m 1.5m
Useage:
Multimedia
Model Number:
HDMI Cable 1.4
Payment:
T/T
Payment & Shipping Terms
Minimum Order Quantity
Negotiation
Price
Negotiation
Packaging Details
1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.
Delivery Time
7~10 Work days
Supply Ability
10000 Piece/Pieces per Day
Product Description

Waterproof 4k Flat 10 Meter HDMI Cable High Speed AWM 20276 For Multimedia





Product Description: Professional HDMI Cable Parametric Test



Item Manufactory 18Gabs 3D ethernert 4k 2160p hdmi cable 2.0
Applications:

Digital cameras and camcorders

Computer monitor, Projector, HDTV, mobile phones

Digital Audio/video devices with HDMI port

Constructions UL Style: UL 20276 O.D. (range): (4.0 to 7.5)±0.2mm

Connector: gold/nickel plated,

90°,180°,360°swivel connector,Right angle adapter available

Conductors: 24/26/28/30AWG,Stranded tinned copper,

Oxygen-free copper conductor

Jacket

Flame-resistance PVC

Low-smoke, flame-retardant TPE

Insulation Foam-PE
Drain wire 24/26/28 AWG stranded tinned copper
Shield

Aluminum foil Mylar, Clear Mylar,

Braid: ≥85% shield with bare copper

Packaging

Giftbox / Blister packaging

PE/polybag/customized

Electrical characteristics

Differential impedance:

Attenuation: -6dB/M max At 3.0GHz

Prop delay: 4.25ns/m normal

Intra pair skew: 10ps maximum

Rise time: 85ps maximum

Pass TDR and NA testing

Features

HDMI is a digital replacement for existing analog video standards

CEA861 signals carried by HDMI are electrically compatible with

the CEA-861signals used by the DVI

Support 4Kx2K, 1080P,3D,an Ethernet data connection and

improved audio

and video capacity, performance and resolution

AL foil wrapped around the whole inner cores and tinned copper braid

shielding, reble screened to provide complete immunity to environment

EMI and RFI
