Product Details:
Payment & Shipping Terms:
|
| Type: | 19pin+1 | AWG: | 26/24 |
|---|---|---|---|
| Speed: | 5Gbps | OD: | 7.0mm |
| Packing: | Double Blister | Resolution: | Support 1080p HD Cables |
| High Light: | hdmi high speed cable,high performance hdmi cable |
||
| SPECIFICATIONS | |
| Conductos | bare copper |
| Insulation | Outer Jacket with protective nylon sleeve. (color optional) |
|
Contacts |
24K Gold Plated |
| Connectors | HDMI Type A Male to Type A Male |
| Available lengths | 20-60m |
| Available terminations | HDMI,19PIN,Male to Male, Version 1.4v, up to 1440P |
| Available gauge | OD:7.3/8.0/9.0mm |
| Certification | RoHS,UL,CE |
| Shielding | AL+ ML+ Braiding+ Ferrite(optional) |
| AWG | 24/26/28 |
| ELECTRICAL: | |
| Quality Control | operation according to regulations & rules in ISO9001:2008 |
| Voltage | DC300V 5M ohm/10ms |
| Insulation Resistance | 10M min |
| Contact Resistance | 2 ohm max |
| Working Temperature | -25C-80C |
| Data transfer rate | 10.2Gbps Max |
| Differential Impedance | 100±10Ω(TDR) |
| FEATURES: |
|
1, Center conductor: high quality digital signal delivered by oxygen-free copper 2, Insulation: Using foamed PE as the insulation, ensure image quality and transmit image signal with stability. 3, Inner shield:100% Aluminum/Mylar foil shield, prevent high frequency noises and interference 4, Outer shield:95% copper braid shield, prevents most low frequency noises and interference. 5, function: suitable for HDTV, home theater, DVD player,projector,PS3,XBOX 360 and other HDMI devices. 6, High density triple shielding for maximum rejection of EMI and RFI 7, Transfer speed: 10.5Gbps 8, connectors: 24K gold-plated to ensure superior signal transfer and lifetime of maximum performance 9, Color optional: Pearl golden, Matter black, Silver, Golden, Shiny black, white porcelain, black porcelain, chrome |
