Name: PCB Slimline SATA Connector Voltage 125V AC Small Footprint Design
Brand: SHUANG YI
SKU: SATA Connector
Rating: 5 (144 reviews)

Home > products > SATA Data Connector >

PCB Slimline SATA Connector Voltage 125V AC Small Footprint Design

serial ata connectors

sata power connector

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

SATA Connector

Request A Quote

Product Details

Type:

SATA Female Connector

Color:

Black

Application:

PCB, PC, Server, Set-Top-Box

Pin Number:

15Pin

Voltage:

125Vac

Gender:

Male

Current:

1.5 Amps

PCB Angle:

Vertical(90 Degree)

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.

Delivery Time

7~10 Work days

Supply Ability

10000 Pieces Per Day

SATA 7p/F 90° Solder Type Wire to Board Connector

Get Best Price

SATA 7p Female Chassis Connector Solder Wire Type 180° Wire to Board Connector

Get Best Price

Video

SATA Male Chassis DIP Gold Plated 15u'' Wire to Board Connector

Get Best Price

Video

SATA 7p Femal Solder Type 180° Au 15u'' Plated Wire to Board Connector

Get Best Price

86-769-28825589

Contact Now

Product Description

PCB Slimline SATA Connector Voltage 125V AC Small Footprint Design

Key Specifications/Special Features:

Description:

The demand for higher bandwidth electronic data transfer in compact storage applications has influenced the migration of parallel to serial bus architecture with a smaller overall product footprint design

One of the new features is the provision for the application of SATA optical drives in laptop computers

This slimline SATA connector is compliant to the 2.6 version specs

The plug-to-ODD retention comes in various versions for manufacturers as options to ensures strong connector retention according to their design

Specifications:

Current rating: 1.5A max.

Contact resistance: 30m ohms at initial state

Insulator resistance: 1,000M ohms at 500V DC

Operating temperature: -35 to +85 degree Celsius

Mating cycles: 50 cycles (internal cabled application)

Applications:

NB, desktop, HDD, storage system, STB, server
