Product Description

This compact board-to-board SATA edge connector is designed for high-density signal and low-voltage power transmission in storage and embedded systems. The 1.27 mm pitch and 22-pin layout follow common SATA interface practices, enabling reliable mating with matching receptacles on HDD, SSD, or controller boards.

Copper-alloy contacts with gold-over-nickel plating provide low contact resistance, corrosion resistance, and long-term signal integrity. The right-angle SMT structure and gull-wing solder legs allow automated reflow soldering and compact layout on densely populated PCBs. The high-temperature, UL94V-0 housing ensures mechanical stability during reflow and long-term operation in demanding environments.

Customization is available for pin count, plating thickness, keying features, and packaging (tape-and-reel or tray) to match different server, automotive, or industrial PCB designs.

Applications

SATA-based HDD and SSD storage devices

Server and data-center backplanes, RAID cards, NAS systems

Industrial PCs, embedded controllers, PLC and motion-control units

Communication equipment, routers, and network appliances requiring compact storage interfaces

Test fixtures and adapter boards for drive evaluation and mass-production testing
