Name: Compact 22P 125V AC SATA Data Connector , PCB SATA Female Connector
Brand: SHUANG YI
SKU: SATA Connector
Rating: 4.6 (162 reviews)

Home > products > SATA Data Connector >

Compact 22P 125V AC SATA Data Connector , PCB SATA Female Connector

sata power connector

sata interface connector

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

SATA Connector

Request A Quote

Compact 22P 125V AC SATA Data Connector , PCB SATA Female Connector

Product Details

Type:

SATA Female Connector

Color:

Black

Application:

PCB, PC, Server, Set-Top-Box

Pin Number:

22Pin

Voltage:

125Vac

Gender:

Female

Current:

1.5 Amps

PCB Angle:

Vertical(90 Degree)

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.

Delivery Time

7~10 Work days

Supply Ability

10000 Pieces Per Day

SATA 7p/F 90° Solder Type Wire to Board Connector

Get Best Price

SATA 7p Female Chassis Connector Solder Wire Type 180° Wire to Board Connector

Get Best Price

Video

SATA Male Chassis DIP Gold Plated 15u'' Wire to Board Connector

Get Best Price

Video

SATA 7p Femal Solder Type 180° Au 15u'' Plated Wire to Board Connector

Get Best Price

86-769-28825589

Contact Now

Product Description

Compact 22P 125V AC SATA Data Connector , PCB SATA Female

Specifications:Serial ATA Connector
1, ROHS,UL,ISO,CE
2, LCP,Gold
3, 7+15P,Male
4, Black

1.27MM0.05 SATA FEMALE SMT TYPE 7+15PIN SATA CONNECTOR

Housnig Material: LCP UL94V-0 RoHS

Contact Material: Phosphor Bronze, T=0.25mm

Contact Plated: Gold Plating in the Contact Area,And Tin Plating in the solder tail area,With 50U Min.Nickel under plating over all.

Current Rating: 0.5Amp

Contact Resistance: 30m ohms.

Insulator Resistance: 500Megohms at 500V DC Min..

Dielectric Withstanding: AC 250V for 1 minute

Operating Temp.: -40°C~+80°C

Max Processing Temp.:230°C for 30~60 seconds

260°C for 10 seconds
