Name: Female CrimpLocking Motherboard SATA Connectors Voltage 40V AC 13 Pin
Brand: SHUANG YI
SKU: SATA Connector
Rating: 4.8 (118 reviews)

Home > products > SATA Data Connector >

Female CrimpLocking Motherboard SATA Connectors Voltage 40V AC 13 Pin

sata power connector

sata interface connector

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

SATA Connector

Request A Quote

Product Details

Applicable Wire Range:

AWG#18-#22

Terminal:

Copper Alloy

Pitch:

1.27mm

Product Name:

Sata 7+6(13P) Connector

M/F Type:

Female

Insulator:

PBT / LCP

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.

Delivery Time

7~10 Work days

Supply Ability

10000 Pieces Per Day

SATA 7p/F 90° Solder Type Wire to Board Connector

Get Best Price

SATA 7p Female Chassis Connector Solder Wire Type 180° Wire to Board Connector

Get Best Price

Video

SATA Male Chassis DIP Gold Plated 15u'' Wire to Board Connector

Get Best Price

Video

SATA 7p Femal Solder Type 180° Au 15u'' Plated Wire to Board Connector

Get Best Price

86-769-28825589

Contact Now

Product Description

Female CrimpLocking Motherboard SATA Connectors Voltage 40V AC 13 Pin

Sata 7+6(13p) pitch crimp type connector :

Poles	7+6Pin	Withstand Voltage
Avaiable	7+6Circuits	Contact Resistance	30mΩ(MAX)
Pitch Between Poles	1.27mm	Insulation Resistance
Rated Voltage	40VAC	Temperature Range	-20°--+85°
Rated Current	1.5A	Aplicable Wire Range

Material:

Insulation:LCP/BPT G/F 94V-0

Termial:Copper Alloy

1. Ni 50u'' Min Plated over Terminal

2. Au Plated on contact Area

3. Tin 80u''Min Plated on solder&crimp Area

Our Advantages:

1. OEM/ODM are welcomed

2. Any color as your enquirement

3. All our materials can be ROHS compliant

4. we passed ISO9001.2008

5. we are glad to make samples according to your drawings and specification

6. Best after sales service and provided

7. All products are 100% tested before shipment

Thank you for your paying attention to our webite,if you are interested in our products pls send me inquiry,pls tell me your special request such as the wire length . model and terminal modle,etc.then i can reply to you soon and save you time.
