Vertical 7 Pin DOM Flash 4GB SATA Data Connector SATA II For PCB

Vertical 7 Pin DOM Flash 4GB SATA Data Connector SATA II For PCB

sata power connector

sata interface connector

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

SATA Connector

Contact Us
Request A Quote
Vertical 7 Pin DOM Flash 4GB SATA Data Connector SATA II For PCB Vertical 7 Pin DOM Flash 4GB SATA Data Connector SATA II For PCB
Product Details
Interface Type:
SATA II
Products Status: Stock Application: Thin Client,PC Terminal,Embeded Devcice,ect Type: Internal St:
NAND Flash
Max Sustained Read:
20MB/s
Average Access Time:
0.3ms
Channels:
1 Channel
ApplicatioN:
Thin Client,PC Terminal,Embeded
Payment & Shipping Terms
Minimum Order Quantity
Negotiation
Price
Negotiation
Packaging Details
1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.
Delivery Time
7~10 Work days
Supply Ability
10000 Pieces Per Day
RELATED PRODUCTS
Good price SATA 7p/M Solder Type Wire to Board Connector online

SATA 7p/M Solder Type Wire to Board Connector

Get Best Price
Good price SATA 7p/F Solder Type Wire to Board Connector online

SATA 7p/F Solder Type Wire to Board Connector

Get Best Price
Good price SATA 7p/F 90° Solder Type Wire to Board Connector online

SATA 7p/F 90° Solder Type Wire to Board Connector

Get Best Price
Good price SATA 7p Female Chassis Connector Solder Wire Type 180° Wire to Board Connector online

SATA 7p Female Chassis Connector Solder Wire Type 180° Wire to Board Connector

Get Best Price
Contact Us
86-769-28825589
Contact Now
Product Description

Vertical 7 Pin DOM Flash 4GB SATA Data Connector SATA II For PCB





Specifications:

1. Vertical 7pin DOM Flash 4GB SATA
2. Dom Flash Max R/W:20/19MB/s
3. Capacity:1GB-32GB
4. CE,FCC,RoHS



Item Model
General interface 7PIN SATA
Performance Capacity(GB) 1GB 2GB 4GB
Sustained Read 17MB/S 20MB/S 23MB/S
Sustained Write 9MB/S 19MB/S 22MB/S
4KB Sequential Read IOPS 1960
4KB Sequential Write IOPS 1630
Average Access time 0.3ms
Storage Media NAND Flash SLC-NAND Flash
Power Consumption input Voltage 5V± 5%
Idle 0.4W
Active 0.75W
Reliability& Endurance Write endurance 8years @100GBytes write and erase per day at 32GB
Read endurance unlimited
Wear-Leveling Algorithm Dynamic and static wear-leveling
Data Retention 10years at 25ºC
MTBF 1,000,000hours
ECC Supports BCH ECC 8bits or 15bits in 512 bytes
Bad Block Management Auto Bad Block Management in system
Environment Operating Temperature 0~70ºC
Non-operating Temperature -40~85ºC
Shock 2,000G(@0.3ms half sine wave)
Vibration 20G(40-2000HZ)
Humidity 5-95%
Warranty 2years
Available unit Available,NO EOL
Testing Platform Intel Pentium E5200 2.5GHz,DDR2 800 2GB×1pcs,G41+IHR7 chipset,Microsoft Windows XP Professional SP2
Testing Software HDBench3.4.0.3, IOMeter 2006.07.27
Physical Dimensions
& Weight		 Height(mm) 8.0± 0.25
Width(mm) 20.8± 0.25
Length(mm) 33.5± 0.25
Weight(g) 10
The read and write speed is limited to this test platform.
