Custom Wire Harness LED 4Pin Switch Molex Connector Wiring Harness

Custom Wire Harness LED 4Pin Switch Molex Connector Wiring Harness

wire harness cable assembly

wire harness assembly

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/ISO14001/SGS/UL/RoHS/Reach

Model Number:

Harness Assembly

Contact Us
Request A Quote
Custom Wire Harness LED 4Pin Switch Molex Connector Wiring Harness Custom Wire Harness LED 4Pin Switch Molex Connector Wiring Harness Custom Wire Harness LED 4Pin Switch Molex Connector Wiring Harness Custom Wire Harness LED 4Pin Switch Molex Connector Wiring Harness
Product Details
Customized:
Yes
Length:
10cm
Housing:
Molex 4Pin
Pitch:
2.5mm
Wire 1:
Black
Wire 2:
White
Payment & Shipping Terms
Minimum Order Quantity
Negotiation
Price
Negotiation
Packaging Details
1.Custom polybag packing 2.Custom paper box packing 3.According to client's request
Delivery Time
7~10 Work days
Supply Ability
300000 per month
RELATED PRODUCTS
Good price 2pin jst 1.0mm pitch Backlight keyboard inverter cable for LCD screen custom online

2pin jst 1.0mm pitch Backlight keyboard inverter cable for LCD screen custom

Get Best Price
Good price Molex Black Large 4Pin To Small 4Pin Green Yellow Power Transfer Wire Harness online

Molex Black Large 4Pin To Small 4Pin Green Yellow Power Transfer Wire Harness

Get Best Price
Good price 2pin and 4 pin molex connector custom Design Assembled custom auto wiring harness online

2pin and 4 pin molex connector custom Design Assembled custom auto wiring harness

Get Best Price
Good price Y Spade Customized 250 Type Terminal Connector Electric Cable Assembly online

Y Spade Customized 250 Type Terminal Connector Electric Cable Assembly

Get Best Price
Contact Us
86-769-28825589
Contact Now
Product Description

Custom Wire Harness LED 4Pin Switch Molex Connector Wiring Harness





Molex connector features:

1: Contact PIN: Brass with Gold plating.

2: Insulation plastic:PA+GF or PUR or LCP

3: Coupling nut/screw: Brass with nickel plating

4: Degree of protection: IP67/ IP68

5: Operating temperature: -25°C ~ +90°C

6: Type: straight and right angled assembly

7: Number of contact: 3pin ,4pin,5pin,8pin,12pin ,17pin



LED 4Pin connector features:

1: Circular connector with M8*1 screw locking.

2: Insulation plastic:PA+GF or PUR or LCP

3: Moulded/screw connection /solder

4: Plug design as per IEC61076-2-104.

5: Cable length is 1m/1.5m/2m/3m/5m/10m.

6: Degree of protection: IP67/ IP68

7: Ambient temperature -25 °C~ 90°C

8: Number of contact: 3pin ,4pin,5pin,8pin,12pin ,17pin



Cable type

UL1015,UL1007,UL1061,UL20276,UL2464,shield or unshield type

Cable color

Optional

Connectors

JAE, HRS, JST, AMP, Dupont, I-pex, Molex, YH, ACES, FCI, DDK, UJU, JWT, Panasonic connectors.

Cable Length

50mm-15000mm.

Processing ways

Crimping, pressing and soldering types.

Pin out connection

As per customer’s request

Connector pitch range

0.5mm-4.2mm

characteristics

Good transferring, clearly pictures, no shaking, and transfer issues

Advantages

Manufacturing factory;

Competitive price and quality;

Short lead time

Applications

LCD/Display/Advertising machine/Phone/Laptop/Computer/PDA

Camera/LCM/Notebook/tablet PC/ HDD

ISO certificate

ISO9001:2015

Service

OEM/ODM products are acceptable.

More information

ISO/RoHS/UL

Performance Test:

100% electrical and electricity performance test
