Name: SFF 8643 12Gb SAS Serial Attached SCSI Cable 36P HD Right Angle For Server
Brand: SHUANG YI
SKU: SFF8643
Rating: 4.5 (151 reviews)

Home > products > Serial Attached SCSI Cable >

SFF 8643 12Gb SAS Serial Attached SCSI Cable 36P HD Right Angle For Server

mini sas cable

sas hard drive cable

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/ISO14001/SGS/UL/RoHS/Reach

Model Number:

SFF8643

Request A Quote

Product Details

Model No:

Mini SAS HD SFF8643

PCBA:

Mini SAS 4I PCB Double Layer

Mini Sas 4I PCB Double Layer:

SAS 2.1 Standard

Rate:

Up To 12Gbps

Connection 1:

36-Pin SFF-8643 Male Mini-SAS Right Angle

Connection 2:

36-Pin SFF-8643 Male Mini-SAS

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

1.Custom polybag packing 2.Custom paper box packing 3.According to client's request

Delivery Time

7~10 Work days

Payment Terms

T/T, L/C

Supply Ability

100000 Pieces Per Month

SFF 8643 12Gb SAS Serial Attached SCSI Cable 36P HD Right Angle For Server

Detailed Product Description:

1) Designed to be used on Storage Devices

2) 10 Gigabits per second

3) 28# parallel pair cable supports 2m long distance

4) 100% open & short test

5) Hi-Pot: DC 300V 10ms

6) Current - Maximum 1.00 Amp

7) Voltage - Maximum 30V

8) Insulation Resistance: 10M OHM Min.

9) Contact Resistance: 2.0 OHM Max

10) Working Temperature: -25ºC ~ +85ºC

11) PCB Contact:Gold plated

Mini SAS HD Introduction:

HD Mini-SAS cable configurations Internal Mini SAS SFF-8643 connector

It is an internal Mini Serial Attached SCSI HD x4 (SFF-8643) to Mini Serial Attached SCSI HD x4 (SFF-8643) cable. It is used for connecting a SAS/SATA adapter to a SAS/SATA backplane with mini-SAS HD connectors.

The High Density (HD) system referenced as HD Mini-SAS (SFF-8643) in the SAS 2.1 standard, meets the 6Gb/s SAS specification.

These new HD Connectors will be used on the SAS 3.0 specification when it is released. Cable material may change but the connectors will be the next generation of SAS to run at 12Gb/s.

Internal HD Mini-SAS Copper Cables Internal Mini SAS SFF-8643 to mini sas High Density HD SFF-8643 data Cable Length: 50cm

Application:

Servers

RAID systems

Storage systems

SAS/SATA HBA interfaces

Direct-attached storage (DAS)
