Mini Serial Attached SCSI (mini SAS) Internal Cable Assemblies provide for high speed transmission up to 6 Gbps. It is an ideal interconnect solution for the growing server and storage market. Mini SAS are designed to significantly reduce the cable size for storage systems currently using SAS 4-lane (4x or 4-lanes of data) and are being widely adopted for next-generation designs.The 36-position internal mini SAS cable assemblies are available in custom lengths of up to one meter. They are also available in three standard sideband configurations. Customized sideband configurations are available upon request.Mini SAS was developed to support data rates at 6.0 Gbps in order to meet the ongoing industry requirement for higher speed and greater bandwidths, This data rate is achieved via the use of high speed differential signals. One assembly is designed to support up to four channels of transmit and receive.
Mini SAS HD Introduction:
March 2012 began a new Mini SAS HD R & D, and dual-port density and low-key as a PCIe card support 6 and 12Gbps SAS applications. The new products, including a connector / card structure and direct-attach copper cables with SAS 2.1 standard and supports the latest SAS protocol for high-speed data transmission in a storage area network (san), data center, switching applications procedures. Mini SAS HD interconnect is fully compatible with 2.1 and SFF SAS - 8644 industry standards.
Mini SAS HD Cable Introduction:
Mini SAS HD direct-attach cables, can provide 4 x (4 channels) or 8 x (8 Channel) cable plug configurations have been developed for the easy wire routing. Wire design combines brand cable outlet 4 pairs double TurboTwin telegraph cable connector backshells, for greater flexibility and tighter bend radius, the wire can be 4 pair cable. The two most shielded wire package aluminum foil and copper braid letter maximize signal integrity and reduce EMI radiation.
In addition, each Mini SAS HD cable incorporates an industry-compliant eepm signature, allows the host to recognize the cable and auto-configuration system settings to optimize the transmission of data signals. One of the key mechanical properties Mini SAS HD connector cable plug is an enhanced pull-to-release hooks, spring hooks at La reduces the insertion force to increase their retention force on the plug with safety and stability. Mini SAS HD cable must have three sizes (26, 28 and 30 AWG) and a length from 0.5 to 7M.
Mini SAS to mini sas cable
Product Description:
30AWG Internal Mini SAS 36pin (SFF-8087) Male to Mini SAS 36pin (SFF-8087) Male Forward Breakout Cable - Black
Serial Attached SCSI (SAS) is a high-speed data storage interface designed for high-throughput and fast data access. Intended primarily for data storage centers, the SAS interface is backwards compatible with SATA. This allows the user to mix more expensive, lower-capacity SAS drives for applications that require faster data access and higher reliability, with lower-cost, higher-capacity SATA drives for applications with lower access speed requirements. Vision carries a full line of quality SAS cables with connectors for every possible application, both internal and external.
This 1/2 meter long cable uses 30 AWG wires and is intended for internal use. It has a one 36-pin SFF-8087 male Mini-SAS plug with locking latch on one end and has one 36-pin SFF-8087 male plugs on the other, allowing you to connect four SATA drives to an SAS controller. This is a Forward Breakout cable, meaning that it is intended to connect to a host/controller on the SAS end and to drives on the SATA end.
Specifications:
Application |
Computer, Server,Power |
Wire Size |
30/32 AWG |
Color |
Black PVC Jacket+Blue Aluminum Foil |
Cable Length |
500mm/0.5M/Customized(other length can enquiry seller) |
Conductor |
Tinned Cooper with 30awg |
Connect Type |
Forward pinout/Forward Breakout |
Connection A Type |
36-Pin SFF-8087 Male Mini-SAS |
Connection B Type |
36-Pin SFF-8087 Male Mini-SAS |
SAS Connector Type |
36P Internal Environment |
Advantages:
1. Fully integrated press-fit design of the container, provides a step placement PCB. |
2. Multi-port function added to allow or 4 x 8 x cable is mated 1-by-2 or 1-by-4 integrated connector. |
3. Integrated container design can be integrated into the radiator, allowing hot solutions long-reach, 4. |
4. Passive - and active-copper cable options available, the ability to extend the reach of copper wire and active. |
5. 4 x 8 x backshell options and more flexible cable options. |
6. Highest-density AOC design, almost double the current density QSFP + AOCs, allows you to choose to use more ports. |
7. Cable is in line with SAS-3 (12 gbp s) (system and optical-mode capability), InfiniBand * (10 gbp s), Ethernet (10 gbp s) and other agreements. Meet the next generation as well as many existing industry standards. |
Application:
ProLiant DL360 G5, DL360 G5 Base, DL360 G5 Performance, DL365, DL365 Base, DL365 G5, DL365 G5 Base, DL365 G5 High Efficiency, DL365 G5 Performance, DL365 Performance
