Product Description

This 7-pin PCB connector is designed for compact, high-reliability SATA-style signal transmission between PCB and cable assemblies or mating board connectors. Gold-plated contacts and a high-temperature thermoplastic housing ensure stable electrical performance, low contact resistance and long-term corrosion resistance in demanding electronic systems.

The through-hole solder tails provide strong mechanical retention to the PCB, making the connector suitable for applications subject to vibration or repeated mating. With 1.27 mm pitch contacts, it offers a good balance of density and creepage distance for high-speed serial links in space-constrained layouts. Customization is available for pin length, plating thickness, housing keying and coding to match your specific PCB design and system requirements.

Applications

Server and storage equipment: HDD/SSD backplanes, RAID cards, host adapter boards

Industrial control and automation: motion controllers, PLC expansion cards, embedded computers

Communication equipment: routers, base-stations, network storage, test instruments

Automotive electronics: infotainment units, data logging modules, power-distribution monitoring boards

Custom cable assemblies and harnesses where compact signal terminals are required
