Two Port Waterproof Micro USB Connector 5P Plug Straddle B Line End For Cable

Two Port Waterproof Micro USB Connector 5P Plug Straddle B Line End For Cable

waterproof micro usb socket

usb waterproof connector

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

USB 3.1 Type-C

Contact Us
Request A Quote
Two Port Waterproof Micro USB Connector 5P Plug Straddle B Line End For Cable Two Port Waterproof Micro USB Connector 5P Plug Straddle B Line End For Cable
Product Details
Use:
Camera, Computer, Mobile Phone
Function:
Sata Sync Charge
Material:
PVC+ABS+Aluminum
Size:
23mmX10mmX5mm
Ports:
2-4
Interface Type:
USB 3.0
Transmisstion Speed:
5Gbps/s
Color:
Gray/Customize
Payment & Shipping Terms
Minimum Order Quantity
Negotiation
Price
Negotiation
Packaging Details
1.Polybay 2.1000pcs of a tray 3.According to client's request
Delivery Time
7~10 Work Days
Payment Terms
T/T, L/C
Supply Ability
100000 Piece/Pieces Per Month
RELATED PRODUCTS
Good price 5 Pin Mobile Phone Waterproof Micro USB Connector , Male Type A USB Connector online

5 Pin Mobile Phone Waterproof Micro USB Connector , Male Type A USB Connector

Get Best Price
Good price On The Go OTG Waterproof Micro USB Connector 24 Pin Stainless Steel Color online

On The Go OTG Waterproof Micro USB Connector 24 Pin Stainless Steel Color

Get Best Price
Good price Type C USB 3.1 Waterproof Micro USB Connector Metal For Mobile Phone online

Type C USB 3.1 Waterproof Micro USB Connector Metal For Mobile Phone

Get Best Price
Good price PCB SMT Mini Cell Phone USB Connector Type B 5 Pin Female Socket Adapter Jack online

PCB SMT Mini Cell Phone USB Connector Type B 5 Pin Female Socket Adapter Jack

Get Best Price
Contact Us
86-769-28825589
Contact Now
Product Description

Two Port Waterproof Micro USB Connector 5P Plug Straddle B Line End For Cable





Micro USB 5P Plug Straddle B Type

1. Material:
Shell: SUS 301 R-1/4H
Insulator: SEE TABLE+30% G.F. UL94V-0
HOOK: SUS 301 R-EH
CONTACT: C5191 R-EH

2. Mechanical:
Mating Force: 35N max
Withdrawal Force: 8N min initial
Durability: 10000 cybles min

3. Electrical:
Current-max(amps): 1.0A
Voltage-max(volts): 30V
Withstanding Voltage: 100V AC
Contact Resistance(ohms): 30 milliohms max
Insulation Resistance(ohms) : 100 Megohms min

4. Plating:
Contacts: Gold 1U" and tin over Nickel Plated
Shell: Nickel over all plating.


5. Enviromental:
Temprature range: -30°C ~+ 80°C
