Product Description

This right-angle SATA 7Pin high-speed cable connector assembly is designed for reliable internal signal transmission between PCB boards, HDD/SSD drives and storage controllers in compact electronic equipment. Both ends use 90-degree SATA male connectors with metal latches, ensuring a secure mating and stable electrical contact even in high-vibration server and industrial environments.

The cable adopts fine-strand copper conductors with controlled 100-ohm differential impedance and a PVC insulated jacket, supporting SATA II and SATA III data rates up to 6 Gb/s. Gold-plated terminals reduce contact resistance and improve anti-corrosion performance, extending the service life of the connector. OEM/ODM customization is available for cable length, wire gauge, color and labeling to match different chassis layouts or harness assemblies.

Applications

Internal SATA data connection between 2.5"/3.5" HDD / SSD and motherboard or RAID card in servers and workstations

High-density storage arrays and NAS systems where right-angle connectors help with tight PCB and housing space

Industrial control computers, DVR/NVR, medical and testing equipment that require stable high-speed signal cables

Customized harness solutions for OEM storage devices and PCB assemblies in electronic and automotive electronics fields
