Name: Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB
Brand: Chongqing ShuangYi Precision Electronic Co., LTD
SKU: Wire To Board Connector
Availability: InStock

Home > Products > Connectors >

Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB

wire to board crimp style connectors

pcb connectors wire to board

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

Wire To Board Connector

Request A Quote

Product Details

Applicable PC Board Thickness:

0.8-1.6mm

Voltage Rating:

1400V AC/DC

Application:

PCB

Terminal:

Phosphor Bronz

Housing:

Nylon UL94V-2(0)

Applicable Wires:

AWG#22~#28

Gender:

Male

Working Temp:

-20~85degrees

Current Rating:

Poles:

2-24

Highlight:

wire to board crimp style connectors

pcb connectors wire to board

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

1.Custom polybag packing 2.Custom paper box packing 3.According to client's request

Delivery Time

7~10 Work days

Supply Ability

100000 Piece/Pieces per Month

High-Reliability SAS 29P 180° IDC Female PCB Connector, Ni/Au/Sn Plated Terminals | Electrical Wire Cable Connector Customization for Server & Power Applications

Get Best Price

SAS 29P 1.27mm Pitch Right-Angle Solder Female Pin Connector with Positioning Peg & Thick Back Cover, 15U" Gold Electronic Signal Terminal Connector for Server, PCB & Power Cable Transmission

Get Best Price

SAS 29P Right-Angle Solder wire Female Cable Connector with Positioning Peg, 15U" Gold-Plated Electronic Electrical terminals Signal Connector for Server & Power Transmission

Get Best Price

SAS 29P Female PCB Connector with Positioning Peg, Ni/Au/Sn Plated Terminals, 1.27mm Pitch Electronic Terminal Connector for Customization in Server & Automotive Applications

Get Best Price

Contact Now

Product Description

Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB

Specification:

1. Poles: 2 to 20

2. Pitch: 1.5mm

3. Current Rating: 1A AC, DC

4. Voltage Rating: 100V AC, DC

5. Temperature Range: -25 to +85°C

6. Contact Resistance: 20mΩ (maximum)

7. Insulation Resistance: 500mΩ (minimum)

8. Withstanding Voltage: 500V AC/minute

9. Material: Wafer Nylon 66 9T, UL94V-0

10. Pin phosphoric copper tin-plate

11. Solder tads phosphoric copper tin-plate

12. Color: Black

13. Applicable Wire Sizes: AWG#22~#28

14. Applicable PC board thickness: 0.6~1.2mm

15. Exchangable: Exchangable with same specification products.

16. Dielectric Strength: ≥500V AC/minute

Application:

Auto mobile, Computer, Electronic, Home appliance, Motorccle, Speed governor, Voltage stabilizer, Inverter Electric meter, Electronic scales, LED Lighting.
