Name: Customized 1.5 mm Wire To Board Connectors Crimp 22 Pin Jst For PCB
Brand: SHUANG YI
SKU: Wire To Board Connector
Rating: 4.8 (118 reviews)

Home > products > Wire To Board Connectors >

Customized 1.5 mm Wire To Board Connectors Crimp 22 Pin Jst For PCB

wire to board power connector

pcb connectors wire to board

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

Wire To Board Connector

Request A Quote

Product Details

Applicable PC Board Thickness:

0.8-1.6mm

Voltage Rating:

1400V AC/DC

Application:

PCB

Terminal:

Phosphor Bronz

Housing:

Nylon UL94V-2(0)

Applicable Wires:

AWG#22~#28

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

1.Custom polybag packing 2.Custom paper box packing 3.According to client's request

Delivery Time

7~10 Work days

Supply Ability

100000 Piece/Pieces per Month

Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB

Get Best Price

Nylon 2.0 mm Wire To Board Connectors , Printed Circuit Board PCB JST PH Connector

Get Best Price

Molex Mini Fit 4.2 mm Pitch Connector Wire to Wire Thin With Tin Plated Pin

Get Best Price

Customized 1.5 mm Wire To Board Connectors Crimp 22 Pin Jst For PCB

Get Best Price

86-769-28825589

Contact Now

Product Description

Customized 1.5 mm Wire To Board Connectors Crimp 22 Pin Jst For PCB

Specification:

1. Poles: 2 to 20

2. Pitch: 1.5mm

3. Current Rating: 1A AC, DC

4. Voltage Rating: 100V AC, DC

5. Temperature Range: -25 to +85°C

6. Contact Resistance: 20mΩ (maximum)

7. Insulation Resistance: 500mΩ (minimum)

8. Withstanding Voltage: 500V AC/minute

9. Material: Wafer Nylon 66 9T, UL94V-0

10. Pin phosphoric copper tin-plate

11. Solder tads phosphoric copper tin-plate

12. Color: Black

13. Applicable Wire Sizes: AWG#22~#28

14. Applicable PC board thickness: 0.6~1.2mm

15. Exchangable: Exchangable with same specification products.

16. Dielectric Strength: ≥500V AC/minute

FAQ

1 fully-Inspection - Products are 100% inspected before shipment
2 Package -Take strong bags/boxes/cartons for package, in order to reduce the damage during the shipments. Tape and reel packing, Clamshell packing, Pallet packing etc are available.

3 Compensation - In case of quality discrepancy or quantity discrepancy, we will do replenishment, or return the money or other better methods after negotiation, to make sure our customers could be satisfied well.
4 Solution - Find the problems, make an effective improvement, and impose more strict quality control.

Terms&Conditions:

We can provide you with insurance, shipping, customs, export documents and quality inspection.
1 Trade Terms - Exworks, FOB, CIF, Door to Door etc…

2 Delivery Method - by sea, by air, or express such as DHL/TNT/UPS etc…
3 Delivery Time- normally 7-15days, could be negotiable when order is urgent.
