2.0 Female USB Type A Connector 4 Pin DIP 90 Degree Jack Socket For Server

China 2.0 Female USB Type A Connector 4 Pin DIP 90 Degree Jack Socket For Server supplier
2.0 Female USB Type A Connector 4 Pin DIP 90 Degree Jack Socket For Server supplier 2.0 Female USB Type A Connector 4 Pin DIP 90 Degree Jack Socket For Server supplier 2.0 Female USB Type A Connector 4 Pin DIP 90 Degree Jack Socket For Server supplier

Large Image :  2.0 Female USB Type A Connector 4 Pin DIP 90 Degree Jack Socket For Server

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: SHUANG YI
Certification: ISO9001/SGS/UL/RoHS/Reach
Model Number: USB2.0/61

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 1.Reel Packing 2.Custom Box Packing 3.According To Client's Request
Delivery Time: 7~10 Work Days
Payment Terms: T/T, L/C
Supply Ability: 100000 Piece/Pieces Per Month
Contact Now
Detailed Product Description
Application: PCB, PC System, Printer, Server Contact Platin: 1'-50u'
Material: ABS/PBT/PA66/LCP Gender: Female
High Light:

usb connector pins

,

usb port connector

2.0 Female USB Type A Connector 4 Pin DIP 90 Degree Jack Socket For Server





Product Name : USB Jack;Type : USB 2.0 Type A Female

Mount Pin Distance : 12mm/0.5";Pin Spacing : 2mm/0.08"

Total Size : 14 x 13 x 7mm/0.55'' x 0.5'' x 0.3'' (L*W*H);Material : Metal, Electronic Parts

Main Color : Black, Silver Tone;Weight : 33g

Package Content : 20 x USB Jack



Product Description:

USB 2.0 Type A Female Port, 4 Pin 90 Degree, soldering or PCB mount.



Electrical:
1. Current Rating: 1.5A/contact terminal
2. Voltage Rating: 30V DC
3. Contact Resistance: 30 milliohms MAX
4. Dielectnic Withstanding Voitage: 500V AC AT Sea Levol
5. Insulation Resistance: 1000MEGA ohms MIN

Mechanical:
1. Connector Mate and Unmate Force:
Mate force: 3.57kgf9(MAX)
Unmate force: 1.02kgf(MIN)
2. Termianl Retenion: 1.2kgf(MIN)

Material:
1. Housing: High Temperature Termaplastics,
94V-0 PBT White/Black
2. Contact: Copper Alloy C2680,Plated Gold in Mating Area; Tin On Solder Talls
3. Shell: Copper Alloy C2680/SPCC,Nickel Plating

Tag:

usb connector pins,

usb port connector
