Name: Molex Mini Fit 4.2 mm Pitch Connector Wire to Wire Thin With Tin Plated Pin
Brand: SHUANG YI
SKU: Wire To Board Connector
Rating: 5 (185 reviews)

Home > products > Wire To Board Connectors >

Molex Mini Fit 4.2 mm Pitch Connector Wire to Wire Thin With Tin Plated Pin

wire to board power connector

pcb connectors wire to board

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

Wire To Board Connector

Request A Quote

Molex Mini Fit 4.2 mm Pitch Connector Wire to Wire Thin With Tin Plated Pin

Product Details

Interface Type:

AC/DC

Housing Material:

Nylon66 UL94V-2/UL94V-0

Specification:

UL, RoHS

Pin Material:

Brasss, Tin-Plated

Size:

4.2mm (0.165")

Species:

Housing

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

1.Custom polybag packing 2.Custom paper box packing 3.According to client's request

Delivery Time

7~10 Work days

Supply Ability

100000 Piece/Pieces per Month

Customize Black Wire To Board Connectors Crimp Type 22 Pin Jst For PC PCB

Get Best Price

Nylon 2.0 mm Wire To Board Connectors , Printed Circuit Board PCB JST PH Connector

Get Best Price

Molex Mini Fit 4.2 mm Pitch Connector Wire to Wire Thin With Tin Plated Pin

Get Best Price

Customized 1.5 mm Wire To Board Connectors Crimp 22 Pin Jst For PCB

Get Best Price

86-769-28825589

Contact Now

Product Description

Molex Mini Fit 4.2 mm Pitch Connector Wire to Wire Thin With Tin Plated Pin

Product Description

1). Plug housing:
Current Rating: 9A AC, DC
Voltage Rating: 600V AC, DC
Operating Temperature:V2: -25ºC to +85ºC
V0: -40ºC to +130ºC
Contact Resistance: 10mΩ max
Insulation Resistance: 1000MΩ min.
Withstanding Voltage: 1500V AC/minute
Material: NylonUL94V-2/NylonUL94V-0
Terminal in housing retention force requirement: 6.5kg(min.)

2). Crimp terminal:
Current Rating: 9A AC, DC
Voltage Rating: 600V AC, DC
Contact resistance: 10mΩ Max
Withstanding Voltage:1500V AC/minute
Terminal Material: brass
Finish: Tin-plated: min.
Thickness: 0.20mm
Qty/reel: 5000pcs.
Terminal in housing retention force requirement: 6.5kg(Min.)

3). Header:
Current Rating: 9A AC, DC
Voltage Rating: 600V AC, DC
Temperature Range: -25° C~+85° C
Contact Resistance: 10mΩ Max.
Insulation Resistance: 1000MΩ Min.
Withstanding Voltage: 1500V AC/minute
Material: HSG: Nylon66 UL94V-0
TER: Brass, Tin plating
