68Pin SAS Female SMT Type PCB Connector with 30u" Gold Plating – Reliable Signal Transmission Connector

68Pin SAS Female SMT Type PCB Connector with 30u" Gold Plating – Reliable Signal Transmission Connector

Place of Origin:

China

Brand Name:

ShuangYi

Certification:

ROHS, HF, ISO 9001, ISO 14001, IATF 16959

Model Number:

SAS-C68F-06M3A6-01LH

Contact Us
Request A Quote
Product Details
Housing Material:
LCP G/F Black UL94V-0
Terminal Material:
Phosphor Bronze (C5191-H) With Gold Plating (30μ" Au)
Mount Type:
SMT Mount
Rated Current / Voltage:
1.5A @ 40VAC
Contact Resistance:
≤ 30 MΩ
Insulation Resistance:
≥ 1000 MΩ
Withstand Voltage:
500VAC / Minute
Operating Temperature:
-20°C ~ +85°C
Plating:
Ni ≥ 50u'' (base), Au ≥ 30u'' (contact Area), Tin ≥ 80u'' (solder Area)
Mating Force:
≤ 59 N
Unmating Force:
≥ 12 N
Durability:
Backplane: 500 Cycles / Cable: 25 Cycles
Salt Spray Time:
48H
Payment & Shipping Terms
Minimum Order Quantity
1000
Price
$1.1-1.8 PCS FOB
Packaging Details
Tape and Reel, 1500 per case, 10KG
Delivery Time
8-15 working days
Payment Terms
T/T
Supply Ability
500000 pcs per month
Product Description

The SAS 68Pin Female SMT Connector is designed for high-speed, stable signal transmission in enterprise-level servers, RAID systems, and data storage equipment. With 30 micro-inch gold plating on contact terminals and precision-engineered phosphor bronze materials, it guarantees excellent conductivity, corrosion resistance, and long-term reliability.

Manufactured by Dongguan Shuangzhuo Electronics Technology Co., Ltd., the connector is produced through fully automated stamping, injection molding, and electroplating processes. Our factory operates independent laboratories for plating thickness verification, electrical performance, and mechanical testing, ensuring every product meets international reliability and durability standards.

The SMT design allows for seamless automated PCB assembly, reducing space consumption and ensuring consistent soldering quality. OEM/ODM customization is available, including pin count, plating thickness, angle, and packaging options, to fit specific design requirements.


⚙️ Applications

  1. Servers and RAID controller systems
  2. Data storage and transmission modules
  3. PCIe and SAS interface devices
  4. Industrial automation control systems
  5. Cloud computing and data centers
  6. Communication equipment and embedded systems

⚠️ Notes

  • Avoid excessive soldering heat and mechanical stress to preserve gold plating integrity.
  • Store in a dry, dust-free environment with anti-static protection.
  • Ensure accurate alignment before PCB mounting to prevent terminal deformation.
  • Custom configurations available for specific signal transmission needs.



68Pin SAS Female SMT Type PCB Connector with 30u" Gold Plating – Reliable Signal Transmission Connector 068Pin SAS Female SMT Type PCB Connector with 30u" Gold Plating – Reliable Signal Transmission Connector 168Pin SAS Female SMT Type PCB Connector with 30u" Gold Plating – Reliable Signal Transmission Connector 2




Item Specification
Product Type SAS 68Pin Female 06 SMT Connector
Mounting Type SMT (Surface Mount Technology)
Pitch 1.27mm
Contact Material Phosphor Bronze (C5191-H)
Housing Material LCP G/F Black UL94V-0
Plating Gold 30u’’ on contact area, Nickel 50u’’ underlayer, Matte Tin 80u’’ on solder tail
Rated Current / Voltage 1.5A @ 40VAC
Contact Resistance ≤30mΩ
Insulation Resistance ≥1000MΩ (500VDC)
Withstand Voltage 500VAC / 1 minute
Mating Force ≤59N
Unmating Force ≥12N
Durability 500 mating cycles (EIA364-09)
Operating Temperature -20°C ~ +85°C
Salt Spray Test 48 hours (gold-plated area)
Environmental Compliance HF + RoHS 2.0
