Name: High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly
Brand: Chongqing ShuangYi Precision Electronic Co., LTD
SKU: SAS-C68F-01S2A5-00LH
Price: 1.00 USD
Availability: InStock

Home > Products > Connectors >

High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly

Place of Origin:

China

Brand Name:

ShuangYI

Certification:

ROHS, HF, ISO 9001, ISO 14001, IATF 16959

Model Number:

SAS-C68F-01S2A5-00LH

Request A Quote

High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly

Product Details

Housing Material:

High-temperature Plastic (UL94V-0)

Terminal Material:

Copper

Mount Type:

Wire Solder Type

Pitch:

1.27 Mm

Rated Current / Voltage:

1.5A @ 40VAC

Contact Resistance:

≤ 30 MΩ

Insulation Resistance:

≥ 1000 MΩ

Withstand Voltage:

500VAC / Minute

Operating Temperature:

-20°C ~ +85°C

Plating:

Ni ≥ 50u'' (base), Au ≥ 15u'' (contact Area), Tin ≥ 80u'' (solder Area)

Mating Force:

≤ 59 N

Unmating Force:

≥ 12 N

Durability:

Backplane: 500 Cycles / Cable: 25 Cycles

Payment & Shipping Terms

Minimum Order Quantity

1000

Price

$1-2.5 PCS

Packaging Details

Tape and Reel, 1500 per case, 10KG

Delivery Time

8-15 working days

Payment Terms

T/T

Supply Ability

500000 pcs per month

SAS 68Pin Female SMT Gold Plated 30u’’ Wire to Board Connector with PCB – High-Speed Server Storage Data Transmission Connector

Get Best Price

SAS 68Pin Female 180° Wire to Board Connector 30u'' Gold Plated High-Speed Signal Transmission PCB Electronic Connector for Server and Storage Devices

Get Best Price

3.96 mm Pitch Printed Circuit Board PCB Connectors Wire To Board Phosphor Bronz Terminal

Get Best Price

Black PCB Wire To Board Connectors , 22 Pin Jst Crimp Type Connector

Get Best Price

Contact Now

Product Description

The SAS 68P Female Wire Solder Type Connector is a high-performance data transmission interface designed for reliable connections in servers, storage systems, and high-speed communication equipment. It features a 1.27mm pitch, supports 1.5A @ 40VAC, and is manufactured with nickel (≥50μ”), gold (≥15μ”), and tin (≥80μ”) plating for superior conductivity and corrosion resistance. The connector maintains excellent electrical stability with ≤30mΩ contact resistance and ≥1000MΩ insulation resistance, and withstands 500VAC for one minute.

Its durable structure ensures consistent mating performance with a mating force ≤59N and unmating force ≥12N, achieving up to 500 backplane cycles and 25 cable cycles. The housing is made from high-temperature UL94V-0 plastic, offering excellent heat resistance and reliability in demanding environments. Ideal for high-density PCB interconnections, SAS signal transmission, and server data storage applications, this connector delivers precision, stability, and longevity in modern electronic systems.

High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly 0

Category	Specification
Pitch	1.27 mm
Rated Current / Voltage	1.5A @ 40VAC
Contact Resistance	≤ 30 mΩ
Insulation Resistance	≥ 1000 MΩ
Withstand Voltage	500VAC / minute
Operating Temperature	-20°C ~ +85°C
Plating	Ni ≥ 50u'' (base), Au ≥ 15u'' (contact area), Tin ≥ 80u'' (solder area)
Mating Force	≤ 59 N
Unmating Force	≥ 12 N
Durability	Backplane: 500 cycles / Cable: 25 cycles
Mount Type	Wire solder type
Housing Material	High-temperature plastic (UL94V-0)

High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly 3

High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly 4

High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly 5

High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly 6

High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly 7

High-Speed SAS 68Pin Female Connector 180 Degree Solder Type Gold Plated 15u Terminal 10.5mm For HDD SSD Server Cable Assembly 8
