Header pH2.0 2*8pin Vertical PCB Mounting with Post 3.0 Au Plated at The Tail Terminals

Product Name:Header PH2.0 2*8PIN Vertical PCB mounting with post 3.0 Au plated at the tail Terminals

Product Overview:
This connector is a high-precision, high-reliability electronic component designed for vertical mounting on printed circuit boards (PCBs).
It complies with the PH2.0 standard, i.e., a pin pitch of 2.0 mm, which ensures a tight fit with compatible sockets or connectors.
The connector features 2 rows of 8 pins, 4 pins per row, for application scenarios that require multiple signal or power connections.
The unique tail gold plating design (3.0 micro inches Au plating) enhances the conductivity and corrosion resistance of the pins, ensuring stable signal transmission and long-term reliability.

Key Features:
1. Pin spacing: 2.0mm, in line with PH2.0 standard, ensuring close fit and stable connection.
2. Number of pins: 2*8PIN, i.e., a total of 16 pins, to meet diversified connection needs.
3. Plating: The end of the pin is plated with 3.0 micro inches of gold (Au), providing excellent conductivity and corrosion resistance.
4. Vertical mounting: Designed to be mounted vertically on the PCB to save space and optimize layout.
5. Insulation post/support post: Usually equipped with an insulating post or support post (post) to enhance the stability of the connection and prevent short circuits.
6. Wide applicability: Suitable for a variety of electronic equipment, such as communication equipment, computers, industrial automation control systems, etc., especially in the need for high-density, high-reliability connections.

Technical specifications
Pin material: copper alloy or other materials with good conductivity.
Insulator Material: Plastic or composite material with high temperature resistance and good insulation performance.
Rated voltage/current: Depends on the specific model, refer to the product manual.
Operating temperature range: Usually depends on the insulator material and plating performance, need to refer to the product specification sheet.
Color: Usually beige, black or other standard colors, depending on supplier and product design.

Caution:
During installation and use, make sure to follow the instructions and precautions in the product manual to avoid damaging the product or affecting performance.
Do not use the product in an environment that exceeds the product specification range as this may affect the reliability and safety of the product.
