High Temperature Wire Crimp Terminals , Jst Sin PCB Board Jumper Wire Terminal

High Temperature Wire Crimp Terminals , Jst Sin PCB Board Jumper Wire Terminal

electrical crimp terminals

crimping wire terminals

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/ROHS/Reach

Model Number:

Quick terminal

Contact Us
Request A Quote
Product Details
Type:
Crimp Terminal
Process:
Stamping
Property:
High Precise, Corrosion Resistance
Material:
Brass, Copper, Stainless Steel
Mould:
Custom Made
Surface Finish:
Nickel, Tin, Zinc Plating, Etc.
Payment & Shipping Terms
Minimum Order Quantity
Negotiation
Price
Negotiation
Packaging Details
1. Reel packing 2. According to client's request
Delivery Time
7~10 Work days
Supply Ability
300000 Per day
Product Description

High Temperature Wire Crimp Terminals , Jst Sin PCB Board Jumper Wire Terminal





Detailed Product Description:

Replace Jst Sin Terminal Pcb Board Connectors To Jumper Wires 1.8mm 0.071 Inch



Quick Detail:

Name

PCB 1.8 Terminal connector

Application

jumper wires

Connector

JST SIN Terminal connector

Temperature

High tempeature

Size

Depend on

Certificate

ROHS, UL,CSA



Descriptions:

It’s time consuming to directly solder the many wires that are required on densely packed printed circuit boards.

The SIN terminal is crimped to a wire, inserted into a hole in PCB, then solder doest not enter the wire, thus ensuring a safe and secure connection.

This terminal is ideal for permanent connection of jumper wires onto a PCB or for connection to external circuits.

1.8,1.6,1.2 option

Series

SIN terminal

Category

Wire to Board Crimp style Connectors

Type

Board-in connector
Crimp style, Board-in connector, Single-circuit type

Current rating

Depends on applicable wires

PC board mounting direction

Top entry



They can replace JST SIN terminal, Molex, ect famous parts.

Specifications:

Terminal

Solderless Terminal

Material

Tin plated brass

Finish

Brass,SN plated,AU-plated,silver-plated

Current rating

Depends on a pplicatble wires

Tab(mm)

6.35x0.8mm

Temperature range

-25 to + 85 C

Applicable Wire range

AWG10~30



Application:

Jumper wires

HVAC - Relays

HVAC - Contactors

PCB Connections

Switches

Terminal blocks
