DIP SMT Solder Crimp Type SAS 29P Serial Attached SCSI Connector For Computer

DIP SMT Solder Crimp Type SAS 29P Serial Attached SCSI Connector For Computer

sas scsi connector

sas power connector

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/SGS/UL/RoHS/Reach

Model Number:

SFF8482/SAS 29P Connector

Contact Us
Request A Quote
DIP SMT Solder Crimp Type SAS 29P Serial Attached SCSI Connector For Computer DIP SMT Solder Crimp Type SAS 29P Serial Attached SCSI Connector For Computer
Product Details
Connector:
Nickel Or Gold Plated
Function:
Charge And Data Sync
Material:
PVC
Conductor:
Copper
Model No:
Mini Sas SFF8088 To SFF8088
Pcba:
Rogers PBT 94V-0
Payment & Shipping Terms
Minimum Order Quantity
Negotiation
Price
Negotiation
Packaging Details
1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.
Delivery Time
7~10 Work days
Payment Terms
T/T, L/C
Supply Ability
10000 Piece/Pieces per Day
RELATED PRODUCTS
Good price SFF8482 SAS 29P Connector DIP SMT Solder Crimp Type For Computer online

SFF8482 SAS 29P Connector DIP SMT Solder Crimp Type For Computer

Get Best Price
Good price DIP SMT Solder Crimp Type SAS 29P Serial Attached SCSI Connector For Computer online

DIP SMT Solder Crimp Type SAS 29P Serial Attached SCSI Connector For Computer

Get Best Price
Good price SFF8482 SAS 29P DIP SMT Solder Crimp Type For Computer online

SFF8482 SAS 29P DIP SMT Solder Crimp Type For Computer

Get Best Price
Good price 29P Serial Attached SCSI Connector SMT Solder Crimp Type For Sever online

29P Serial Attached SCSI Connector SMT Solder Crimp Type For Sever

Get Best Price
Contact Us
86-769-28825589
Contact Now
Product Description

DIP SMT Solder Crimp Type SAS 29P Serial Attached SCSI Connector For Computer



Technical details:

The Serial Attached SCSI standard defines several layers (in order from highest to lowest): application, transport, port, link, PHY and physical. Serial Attached SCSI comprises three transport protocols:

  • Serial SCSI Protocol (SSP) – for command-level communication with SCSI devices.

  • Serial ATA Tunneling Protocol (STP) – for command-level communication with SATA devices.

  • Serial Management Protocol (SMP) – for managing the SAS fabric.

Specification:

1. Poles: 29pin

2. Withstand Voltage: 500VAC/minute

3. Avaiable: 7Circuits

4. Contact Resistance: 30mΩ(MAX)

5. Pitch Between Poles:1.27mm

6. Insulation Resistance:1000MΩ(MAX)

7. Rated Voltage: 40VAC

8. Temperature Range: -20°--+85°

9. Rated Current:1.5A

10. Aplicable Wire Range: AWG #18-#30&#26-#30

11. Operating temp: -55~105



Material:

1. Terminal: Phosphor Bronze, Gold Plated

2. Housing: LCP+GF

3. Insulation:LCP/BPT G/F 94V-0

4. Termial:Copper Alloy

5. Ni 50u'' Min Plated over Terminal

6. Au Plated on contact Area

7. Tin 80u''Min Plated on solder&crimp Area

8. Shell: Copper Alloy

9. Plated Su 80 u on Contact Area

10: Ni 40u Plated over shell
