High-Performance Double Row 2x3p Black Elbow Pin Header for Stable Signal Transmission

High-Performance Double Row 2x3p Black Elbow Pin Header for Stable Signal Transmission

Place of Origin:

China

Brand Name:

Shuangyi

Certification:

ISO9001,ISO14001

Model Number:

PZQM-B04B06-D19T3-01LR

Contact Us
Request A Quote
Product Details
Type:
Adapter,round Pin Header,DIN,Box Header,USB
Application:
PCB,Ethernet,All Electric Area,Automotive
Gender:
Male/Female
Product Name:
Pin Header/female Header,Male Pin Header,2.54 Mm Female Header
Color:
Black,white/black Plastic,Black/OEM
Pin:
6 Pins
Contact Material:
Copper Alloy
Plating:
Au Plated/Tin Plated
Payment & Shipping Terms
Minimum Order Quantity
Negotiation
Price
Negotiation
Packaging Details
1.Custom polybag packing 2.Custom paper box packing 3.According to client's request
Delivery Time
According to clients' request
Payment Terms
L/C, T/T
Supply Ability
100000 Pieces Per Month
Product Description

Product Description

Product name Double row 2*3p black elbow header
Pin Count 2*3p
Plating tin

1. Basics

  • Type: Double row pin header with 2 rows of 3 pins each, totaling 6 pins.
  • Color: Black, providing a sleek and professional aesthetic.
  • Design: Features an elbow (or right-angle) design, allowing for flexible connections in space-constrained environments or where a specific angle is required.

2. Technical Specifications

  • Pin Pitch: Typically 2.54mm, the standard pitch for many electronic connectors, but specific values may vary by product.
  • Pin Count: 3 pins per row, totaling 6 pins (2x3p).
  • Materials:
    • Contact Material: Likely copper alloy for excellent conductivity and processability.
    • Insulator Material: High-temperature plastic such as nylon 6T, with UL94V-0 flammability rating, ensuring durability and resistance to heat.
  • Electrical Performance:
    • Current Rating: May reach up to 3.0A or higher, depending on the product design.
    • Voltage Rating: May be 250V AC/DC or higher, also subject to specific product specifications.
    • Contact Resistance: Low contact resistance ensures accurate and stable signal transmission.

3. Applications

  • Widely used on PCBs (Printed Circuit Boards), particularly in applications requiring high-density connections and space savings.
  • Found in various electronic devices such as computers, communication equipment, and industrial control systems.

4. Additional Features

  • Plating: Pins may be plated with gold or tin-nickel alloy for enhanced corrosion resistance and conductivity.
  • Packaging: Typically packaged in trays or cardboard boxes for convenient transportation and storage.
  • Customization: Some suppliers may offer customization options, including color, size, and pin count adjustments.
