Name: PVC Power Serial ATA High Speed SATA Cable 15 Pin SATA To ESATA 7 Pin
Brand: SHUANG YI
SKU: SATA Data Cable
Rating: 5 (129 reviews)

Home > products > SATA Data Cable >

PVC Power Serial ATA High Speed SATA Cable 15 Pin SATA To ESATA 7 Pin

sata power cable

serial ata data cable

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

SHUANG YI

Certification:

ISO9001/ISO14001/SGS/UL/RoHS/Reach

Model Number:

SATA Data Cable

Request A Quote

PVC Power Serial ATA High Speed SATA Cable 15 Pin SATA To ESATA 7 Pin

Product Details

Delivery Time:

About 3-10 Working Days

Jacket:

PVC

Payment Terms:

T/T, Paypal, Western Union

Insulation Material:

PVC

Conductor Material:

Copper

Type:

Low Voltage

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

1.Custom polybag packing 2.Custom paper box packing 3.According to client's request

Payment Terms

T/T, L/C

Supply Ability

100000 Pieces per Month

PVC Power Serial ATA High Speed SATA Cable 15 Pin SATA To ESATA 7 Pin

Specifications:

We can supply high-quality, a different capacity, a variety of styles of the cable, Serial ATA Cable
High Speed Serialized AT Attachment Revision 1.0 (29-August - 2001)
Device Under Test (DUT) Information
Report Title : Serial ATA Cable Assembly Test Report
Dut Length : 0.5 Meters Temperature : 22 XC
Batch Number : Bundle Number : 1
Test Fixture : Serial ATA Manual Test Fixture Tested Pairs : 2 Pairs
Engineer : Sky
Remark : LCP

Tested Parameters List
1. TDR : Differential Impedance
2. TDR : Common Mode Impedance
3. TDR : Cable Pair Match Impedance
4. TDR : Intra Pair Skew (TDT Mode)
5. TDR : Risetime (TDT Mode)

Advantages
1. Lower Voltage
The level of voltage to the Serial ATA is differential 500 mV , it is more suitable for PC ' s technical request than the 5 Volt Parallel ATA , and also can save more power.
2. Pin Pitch
Serial ATA connector includes a line of 7Pin signal terminal and a line of 15 Pin power terminal . These two lines of terminals can be detached to the freestanding tie-in . So ,
it did not only reduce its body size , but also enlarge its transpositional space .
3. Transfering Speed
It almost has no potential to quicken the Parallel ATA 's transfering speed . But to the
Serial ATA , the transfering speed for its incunabular design is 150MB/s , now it is striding forward to the speed of 300MB/s and even to 600MB/s .
