SATA 7p/M SMT Type 90° 15u'' Wire to Board Connector

Product Name: SATA 7P/M SMT Type 90° 15u'' Wire to Board Connector

Product Overview
This connector is a surface mount (SMT) wire to board connector designed specifically for the SATA interface with 90 degree bent pins for vertical or horizontal mounting on circuit boards. It features a 7-pin (Pin) design, is SATA compliant, and has a 15 micro-inch (15u'') gold plating for improved electrical performance and corrosion resistance.

Key Features
1. 7-Pin design: Compliant with SATA interface standards to ensure compatibility with SATA devices.
2.SMT type: Surface mount design for easy automation and improved productivity.
3.90 Degree Bend Pin: The pins are bent at 90 degrees, which facilitates flexible layout and installation on the circuit board.
4. Gold plating layer: The gold finger part is treated with 15 micro inches of gold plating to improve the conductivity and corrosion resistance.
5. High-quality materials: Made of high-quality materials to ensure the stability and reliability of the connector.

Technical parameters
Interface type: SATA 7P/M
Mounting method: SMT (surface mount)
Pin angle: 90°
Plating thickness: 15u'' (15 micro inches)
Applicable cable: SATA cable
Operating Temperature: Depends on the specific product, usually industrial grade temperature range
Operating humidity: product-specific, usually wide range of humidity environment

Application Areas
This connector is widely used in electronic devices that require a SATA interface connection, such as personal computers, servers, storage devices, data centers and so on. It is especially suitable for applications that have strict space requirements or require highly reliable connections.

Caution
During installation and use, please make sure that the connector pins and circuit board interface are not damaged, so as not to affect the quality of data transmission.
Please install and use the connector correctly according to the product manual to avoid damage to the equipment caused by improper operation.
Check the connection status of the connector regularly to ensure the stability and reliability of data transmission.
