SATA 7p Male DIP 180° Au 30u'' Plated Wire to Board Connector

I. Basic overview
Type: SATA 7P Male DIP 180° Au 30u "Plated Wire to Board Connector, a 7-pin, male, DIP (double in-line) package, 180 degree bending Angle, and 30 microinches of gold plating thickness.
Application: Widely used in computers, servers, data storage devices and other fields, as a SATA hard disk, optical drive and other storage devices and the key connection components between the motherboard.

II. product characteristics
1. High-performance gold-plated pin:
The pin surface is gold-plated with 30 microinches, which not only improves the corrosion resistance and wear resistance of the pin, but also ensures good conductance Electrical performance and signal transmission quality.
2.DIP in-line package:
The DIP package allows the connector to be plugged directly into the socket on the board, simplifying the installation process and improving the connection Stability and reliability.
3.180 degree bending Angle:
The unique 180-degree bending design allows the connector to be flexibly installed in a space-limited environment to meet the needs of different application scenarios.
4. High-speed transmission:
It supports high-speed data transmission characteristics of SATA interface, which can meet the requirements of modern storage devices for data transmission speed.
5. Hot Swap support:
Allows storage devices to be connected or disconnected while the system is running, improving the flexibility and efficiency of data transfer.
6. Stable and reliable:
The use of high-quality materials and advanced production processes to ensure the connector's stable performance and reliability in a variety of environments.

III. Technical specifications
Pin count: 7 pins
Interface type: SATA
Package form: DIP in line
Bending Angle: 180°
Gold plating thickness: 30u "(micro inch)
Electrical performance:
Rated current: depends on the specific product
Contact resistance: Low value to ensure signal transmission quality
Insulation resistance: High value to ensure electrical isolation
Physical size: including the connector height, width, pin spacing, etc., the specific value needs to refer to the product specification.

IV. Application scenarios
It is mainly used when the mainboard of a computer or server needs to be connected to a SATA storage device.

V. Precautions
During use, ensure that the connector is correctly connected to the device to avoid signal transmission problems caused by poor contact.
Pay attention to the use of the connector environment, avoid the use of humid, high temperature or strong electromagnetic interference environment, to ensure the stability and reliability of data transmission.
During the welding process, follow the relevant welding process requirements to ensure the welding quality and avoid damage to the connector.
