Vertical DIP External SATA 7 Pin Connector Male To Female For Laptop

ELECTRICAL

Internal magnetics are 100% electrically tested for functionality per IEEE802.3 requirement

High performance for maximum EMI suppression

350uH minmum OCL with 8mA bias current

1. Current Rating

1.5 amps

2. Voltage Rating

125vac

3.Insulation Resistance

500 MΩmin

4. Contact Resistance

30 MΩmax

5. Withstanding Voltage

AC 1000V RMS 50Hz or 60Hz 1 min

Instertion Loss:

-1.2dB Maximum @100KHz-100MHz

Return Loss:

-18dB Minimum @1MHz-30MHz

-14dB Minimum @30MHz-60MHz

-12dB Minimum @60MHz-80MHz

Common
Mode Rejection:

-30dB Minimum @1MHz-100MHz

Cross Talk:

-30dB Minimum @1MHz-100MHz

MECHANICAL

1. Insertion Force

2 CONTACTS....350g 4 CONTACTS….500g 6 CONTACTS….750g

8 CONTACTS….900g 10 CONTACTS....1050g

2. Retention Strength

7.7KG.F min between jack and plug

3. Durability

750 mating cycles min

MATERIAL

1. Housing

ABS RESIN(UL94V-0) PBT(UL94V-0) PA66(UL94V-0) PA46(UL94V-0) LCP(UL94V-0)

2. Contact Wire

Diameter 0.45mm phosphor bronze gold plating over nickel 0.35mm thickness hosphor bronze alloy selective gold plating over nickel

3. Shield

0.20~0.25mm thickness brass with tin plated

4. Gold Plating

3u inch,6u inch,15u inch,30u inch,50u inch

5. LED Specification

Standard LED Color:

LED Wavelength:

Forward (V MAX):

Typical (V TYP):

Luminous Intensity:

Green

560-580 nm

2.5V

2.1-2.2V

9-25 MCD

Yellow

580-610 nm

2.5V

2.1-2.2V

9-30 MCD

Orange

580-610 nm

2.5V

2.1-2.2V

50-100 MCD

LED intensity/wavelength measured with Photo Research PR-650 Colormeter

With a forward current of 20 mA,Absolute Maximum Ratings (Ta=25℃)

ENVIROMENTAL

Operating Temperature:

-40℃ to 85℃

Working Temperature

-40℃ to 85℃

APPLICATION

NETWORKING PRODUCTS: NIC, HUB, SWITCH, ROUTER, BRIDGE,WORK

STATION: PC/SYSTEM, PRINTER,SERVER,NB,IACABLE MODEN,XDSL APPLICATION, SET-TOP-BOX
