PC SMT Male Connector 7 Pin ESATA Port Connector Crimp Type With Latch

China PC SMT Male Connector 7 Pin ESATA Port Connector Crimp Type With Latch supplier
PC SMT Male Connector 7 Pin ESATA Port Connector Crimp Type With Latch supplier PC SMT Male Connector 7 Pin ESATA Port Connector Crimp Type With Latch supplier

Large Image :  PC SMT Male Connector 7 Pin ESATA Port Connector Crimp Type With Latch

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: SHUANG YI
Certification: ISO9001/SGS/UL/RoHS/Reach
Model Number: ESATA Connector

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.
Delivery Time: 7~10 Work days
Payment Terms: T/T, L/C
Supply Ability: 10000 Pieces Per Day
Contact Now
Detailed Product Description
SATA 7 Pin: Straight SMT: 180 Degree
Useage: Computer Housing: LCP+GF
Voltage: 125Vac Operating Temp: 55~105
High Light:

esata usb connector

,

esata power connector

PC SMT Male Connector 7 Pin ESATA Port Connector Crimp Type With Latch





Specifications:

SATA connector, B type, 7 pin, Male, Straight, DIP, 180 degree

a. SATA connector with one arm
b. 7P Male B type

c. Housing: LCP+GF

d. Terminal: Brass, Gold Plated



Mechanical:
a. Insertion Force: 45N max
b. Withdrawal Force: 10N min



Specification:

a. Current Rating: 1.5A
b. Contact Resistance: 30 milliohms max.
c. Insulation resistance: 1000 megohms min.
d. Dielectric withstanding voltage: 500 VAC.

e. Operating temp: -55~105
