Straight Micro External SATA 7 Pin Connector Solder Type 180 Degree DIP

China Straight Micro External SATA 7 Pin Connector Solder Type 180 Degree DIP supplier
Straight Micro External SATA 7 Pin Connector Solder Type 180 Degree DIP supplier Straight Micro External SATA 7 Pin Connector Solder Type 180 Degree DIP supplier

Large Image :  Straight Micro External SATA 7 Pin Connector Solder Type 180 Degree DIP

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: SHUANG YI
Certification: ISO9001/SGS/UL/RoHS/Reach
Model Number: ESATA Connector

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.
Delivery Time: 7~10 Work days
Payment Terms: T/T, L/C
Supply Ability: 10000 Pieces Per Day
Contact Now
Detailed Product Description
DIP: 180 Degree SATA 7 Pin: Straight
Use: Computer Type: A
Current: 1.5 Amps Gender: Female
High Light:

external sata connector

,

esata usb connector

Straight Micro External SATA 7 Pin Connector Solder Type 180 Degree DIP​





Specifications:

SATA connector, A type, 7 pin, Male, Straight, DIP, 180 degree,

a. SATA connector with two arms
b. 7P Male A type

c. Housing: LCP+GF

d. Terminal: Phosphor Bronze, Gold Plated



Mechanical:
a. Insertion Force: 45N max
b. Withdrawal Force: 10N min



Specification:

a. Current Rating: 1.5A
b. Contact Resistance: 30 milliohms max.
c. Insulation resistance: 1000 megohms min.
d. Dielectric withstanding voltage: 500 VAC.

e. Operating temp: -55~105
