Product Details:
Payment & Shipping Terms:
|
| Application: | Computers, Laptops,Mobile Phones | Pole: | 29Pin |
|---|---|---|---|
| Color: | Black/Customized | Gender: | Female |
| Pitch: | 1.27mm | Rated Voltage: | 40VAC |
| Insulator: | LCP | Avaliable: | 7Circuits |
| High Light: | sas scsi connector,sas power connector |
||
Floating SATA Connector Floating SATA
Applications:
1. SSD
2. Desktop
3. Servers
4. Vehicle-mounted
Features and Benefits:
1. Transmission rate: 6 Gbps.
2. Meet SATA 3.2 specification.
3. Floating up and down
Mechanical Performance:
Mating Force and Un-mating Force
Condition: EIA 364-13. Insert and extract at a speed of 25mm/minute.
Mating Force: 45 N maximum.
Un-mating Force: 10 N minimum.
Electrical Performance:
1. Contact Resistance 30mohm max. initial, 15mohm maximum after stress test.
2. Dielectric Withstanding Voltage 500 VAC for 1 minute no breakdown.
3. Insulation Resistance 1000 Mega ohms minimum.
Signal Integrity:
1. Mated Connector Impedance: 100 ohm±15%
2. Common Mode Impedance: 25 to 40 ohms
3. Insertion loss: -6dB maximum up to 4.5 GHz,
4. Maximum Crosstalk: -26 dB up to 4.5 GHz
