Serial Attached SCSI SAS HDD Connector Rectangular SATA Board To Wire Connectors

China Serial Attached SCSI SAS HDD Connector Rectangular SATA Board To Wire Connectors supplier
Serial Attached SCSI SAS HDD Connector Rectangular SATA Board To Wire Connectors supplier Serial Attached SCSI SAS HDD Connector Rectangular SATA Board To Wire Connectors supplier

Large Image :  Serial Attached SCSI SAS HDD Connector Rectangular SATA Board To Wire Connectors

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: SHUANG YI
Certification: ISO9001/SGS/UL/RoHS/Reach
Model Number: SFF8482/SAS 29P Connector

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.
Delivery Time: 7~10 Work days
Payment Terms: T/T, L/C
Supply Ability: 10000 Piece/Pieces per Day
Contact Now
Detailed Product Description
Type: Board-to-wire, SATA, Serial Attached SCSI Shape: Rectangular
Connection Type: Through-hole, Blind Mate Current: 1.5 A
Insulator: LCP Avaliable: 7Circuits

Serial Attached SCSI SAS HDD Connector Rectangular SATA Board To Wire Connectors





Detailed Product Description:

1. kinds of connectors are available:Molex,JST,Tyco,AMP,Yeonho,etc

2. mainly product:wire harness,housing,terminal,wafer,SMT,pin/female header connector,etc

3. Best price,stable quality,quick delivery,rich experience

4. OEM is acceptable

5 100% tested before delivery

6. ISO9001,SGS,ROHS,UL

This 22-position signal and power unit has EMLB contacts to make it work for hot swap functions and uses blind mate polarization to make it easier for cables to link up. This has a PCB retention clip to manage the unit and works with SATA receptacles and 3M SCSI units. This works with SATA 2.6 standards as well.



Material:

Technical Information



  • SFF-8482 specification

  • 1.27 mm in-line contacts

  • EMLB contacts for HOT plugging

  • Extended height combo receptacle for backplane

  • Low voltage requirement (1600 mV peak-to-peak)

  • Point-to-point signaling

  • Accommodates 3.3, 5.0, and 12 V requirements

  • Blind-mate guide

  • 2.5” and 3.5” HDD interface

  • Serial Advanced Technology Attachment (SATA) interoperability



FEATURES & BENEFITS:

Serial Attached SCSI (SAS) Connectors are offered in both device plug and backplane receptacle combo formats and are designed to the SFF-8482 specification. This standard was designed to support internal backplane environments which allow a direct connection from the hard disk drive (HDD) to the backplane (device-to-host). The SAS combo plug, 29 position from 3M is used on the device side (optical or HDD) and has a variety of features that makes it appealing for high-volume environments. The plug connector is available in two different configurations: surface-mount, vertical and straddle-mount, right angle. The surface-mount plug version is equipped with PCB guides to ensure the proper alignment between the HDD PCB and connector contact tails. The 3M SATA plug, 22 positions is designed for interoperability with the 29 position SAS receptacles.



Our Excellent Service as below:

1. We specialize in this field ,with good quality and pretty competitive price.

2. Variety of Designs, Provide Professional & Original Fashionable Designs, with more than

thousand designs.

3. Original manufacturer with direct factory price, Competitive & Fashionable.

4. High management Standard for quality control.

5. Small order acceptable: 1000pcs are welcome.

6. Safe payment terms: T/T, Western Union, Paypal are available.

7. Prompt Delivery & Lowest shipping cost : We can get low discount for the freight .

8. OEM available, Customers' designs are warmly welcome.
