Product Details:
Payment & Shipping Terms:
|
| Application: | Multimedia | Color: | Black |
|---|---|---|---|
| Connector Color: | Gold | Gender: | Male |
| Outer Diameter: | 8.0mm | Shielding: | Non-Shielded |
| High Light: | hdmi high speed cable,1.4 version hdmi cable |
||
Specifications:
HDMI CONNECTOR,HDMI ADAPTER,HDMI TYPE A PLIG,HDMI PLUG,HDMI,CONNECTOR
Material:
| 1. Housing: LCP/ABS Resin(UL 94V-0) 2)/GLASS FILLED PBT (UL 94V-0) |
| 2. Spring Wire: 0.45mm DIA phosphor bronze gold plating over nickel |
| 3. Contact: Copper alloy 0.35mm thicheness phosphor bronz alloy selctive gold plasting over nickel |
| 4. Shell:Copper 0.25mm thicheness copper alloy with Tin plated |
| 5. Contact Plating: 30u,15u,3-5u,G/F |
| 6. Shell Plating: G/F or Nickel |
Electrical:
| 1. Contact Current Rating: 0.5A MIN |
| 2. Voltage Rating: 40V AC(rms) |
| 3. Withstanding Voltage: 300VAC for 1 minute |
| 4. Insulation Resistance: 100Mega-Ohms min |
| 5. Contact Resistance: 30 Milli-Ohms Max |
Machanical:
| 1. Insertion Force:44.1N Max |
| 2. Withdrawal Force:6.9N Min |
| 3. Insertion Force: 2Contacts 350g 4Contacts 500g 6Contacts 750g 8Contacts 900g 10Contacts 1050g |
| 4. Rention Strength: 7.7Kg Between Jack and Plug |
| 5. Durablity: 600 Mating cycles mini |
Environmental:
| 1. Operating Temperature:-25C to +85C |
