Double Sided Contact JST NH Wire To Board Crimp Style Connectors with Locking Device

Double Sided Contact JST NH Wire To Board Crimp Style Connectors with Locking Device

Product Description:

Double Sided Contact JST NH Wire To Board Crimp Style Connectors With Locking Device

Quick Detail:
Name JST NH 2.5mm connector Application Printed circuit boards, wire to boards
Connector NH disconnectable connector Circuits/poles/pins 2~25
Pitch 2.5mm Certificate ROHS, UL, HF


Descriptions:
Thin, low-profile can meet the demand for high-density connection of internal wire to PCB.
With locking device;
Molded-in header with wide and sturdy posts
Double-side contact;
Top, side and bottom entry allows the wire to be perpendicular or parallel to the PCB in any direction.
They can be equal JST, Molex, Digikey, CVILUX, JAE, JWT ect famous parts.

Specifications:
Housing Equivalent of JST NH H(2~25)P-SHF-AA
Contact: SHF-001T-0.8BS SHF-002T-0.8BS Tin plated, Reel package
Shrouded Header/wafer Top entry: B(2~25)P-SHF-1AA; Side entry: BS(2~25)P-SHF-1AA; Bottom entry: BE(2~25)P-SHF-1AA
Number of Rows Single
Current rating 3A AC, DC
Voltage rating 250V, AC, DC
Wire range AWG22


Application:
Robotics, PCB assemblies, Signal-jumpers; High-power solutions, Computers, Notebook PC, LCD, Digital camera, PAD, Led lamp, Scanner, BT alarm button, taximeter, Fingerprint machine, flat colorful TV, power source for electronic communication, Business machine, Telecommunications, Home appliances, Medical equipment, Cell phone, Security systems, Car, ATM Machines, Inkjet, MFP/LBP, Projector, RAILWAYPRODS, etc. Industrial.
