SAS 29P Mini SAS Connector DIP SMT Solder Crimp Type For Media

China SAS 29P Mini SAS  Connector DIP SMT Solder Crimp Type For Media supplier
SAS 29P Mini SAS  Connector DIP SMT Solder Crimp Type For Media supplier SAS 29P Mini SAS  Connector DIP SMT Solder Crimp Type For Media supplier

Large Image :  SAS 29P Mini SAS Connector DIP SMT Solder Crimp Type For Media

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: SHUANG YI
Certification: ISO9001/SGS/UL/RoHS/Reach
Model Number: SFF8482/SAS 29P Connector

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.
Delivery Time: 7~10 Work days
Payment Terms: T/T, L/C
Supply Ability: 10000 Piece/Pieces per Day
Detailed Product Description
Application: Computers, Laptops,Mobile Phones Pole: 29Pin
Color: Black/Customized Gender: Female
Pitch: 1.27mm Rated Voltage: 40VAC
Insulator: LCP Avaliable: 7Circuits
High Light:

sas power connector

,

sas hd connector

 SAS 29P Mini SAS Connector DIP SMT Solder Crimp Type For Media



Specification:

1. Poles: 29pin

2. Withstand Voltage: 500VAC/minute

3. Avaiable: 7Circuits

4. Contact Resistance: 30mΩ(MAX)

5. Pitch Between Poles:1.27mm

6. Insulation Resistance:1000MΩ(MAX)

7. Rated Voltage: 40VAC

8. Temperature Range: -20°--+85°

9. Rated Current:1.5A

10. Aplicable Wire Range: AWG #18-#30&#26-#30

11. Operating temp: -55~105



Material:

1. Terminal: Phosphor Bronze, Gold Plated

2. Housing: LCP+GF

3. Insulation:LCP/BPT G/F 94V-0

4. Termial:Copper Alloy

5. Ni 50u'' Min Plated over Terminal

6. Au Plated on contact Area

7. Tin 80u''Min Plated on solder&crimp Area

8. Shell: Copper Alloy

9. Plated Su 80 u on Contact Area

10: Ni 40u Plated over shell



Mechanical:

1. Insertion Force: 45N max

2. Withdrawal Force: 10N min


Applications:

Products are widely used in computers, laptops, mobile phones, communications, medical and electrical equipments.
