SFF 8482 Serial Attached SCSI SAS SATA Connector 1.5A 1000 MΩ Insulation Resistance

China SFF 8482 Serial Attached SCSI SAS SATA Connector 1.5A 1000 MΩ Insulation Resistance supplier
SFF 8482 Serial Attached SCSI SAS SATA Connector 1.5A 1000 MΩ Insulation Resistance supplier SFF 8482 Serial Attached SCSI SAS SATA Connector 1.5A 1000 MΩ Insulation Resistance supplier

Large Image :  SFF 8482 Serial Attached SCSI SAS SATA Connector 1.5A 1000 MΩ Insulation Resistance

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: SHUANG YI
Certification: ISO9001/SGS/UL/RoHS/Reach
Model Number: SFF8482/SAS 29P Connector

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.
Delivery Time: 7~10 Work days
Payment Terms: T/T, L/C
Supply Ability: 10000 Piece/Pieces per Day
Detailed Product Description
Application: Computers, Laptops,Mobile Phones Pole: 29Pin
Color: Black/Customized Gender: Female
Pitch: 1.27mm Rated Voltage: 40VAC
Insulator: LCP Avaliable: 7Circuits
High Light:

sas scsi connector

,

sas power connector

SFF 8482 Serial Attached SCSI SAS SATA Connector 1.5A 1000 MΩ Insulation Resistance




Key Specifications/Special Features:

Voltage: 30V AC

Current: 1.5A

Contact resistance: 30mΩ maximum initial

15mΩ maximum change allowed

Dielectric withstanding voltage: 500V AC minimum at sea level for 1min

No discharge, flash over or breakdown

Current leakage: 0,5mA maximum

Insulation resistance: 1000 MΩ minimum

Operating temperature: 0 to +55°C

Non-operating temperature: -40 to +85°C


Primary Competitive Advantages:

Green Product

International Approvals

Price

Product Features

Product Performance

Quality Approvals

Service
