SFF 8482 SAS Serial Attached SCSI Connector 29 Pin DIP SMT Solder Crimp Type

China SFF 8482 SAS Serial Attached SCSI Connector 29 Pin DIP SMT Solder Crimp Type supplier
SFF 8482 SAS Serial Attached SCSI Connector 29 Pin DIP SMT Solder Crimp Type supplier SFF 8482 SAS Serial Attached SCSI Connector 29 Pin DIP SMT Solder Crimp Type supplier

Large Image :  SFF 8482 SAS Serial Attached SCSI Connector 29 Pin DIP SMT Solder Crimp Type

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: SHUANG YI
Certification: ISO9001/SGS/UL/RoHS/Reach
Model Number: SFF8482/SAS 29P Connector

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 1.Polybay 2.1000pcs of a tray 3.Or accroding to your request.
Delivery Time: 7~10 Work days
Payment Terms: T/T, L/C
Supply Ability: 10000 Piece/Pieces per Day
Detailed Product Description
Application: Computers, Laptops,Mobile Phones Pole: 29Pin
Color: Black/Customized Gender: Female
Pitch: 1.27mm Rated Voltage: 40VAC
Insulator: LCP Avaliable: 7Circuits
High Light:

sas scsi connector

,

sas power connector

SFF 8482 SAS Serial Attached SCSI Connector 29 Pin DIP SMT Solder Crimp Type





ATA/SATA Connector

ATA/SATA Connector with 30 Mohms Contact Resistance
Primary Competitive Advantages: Green Product
Main Export Markets: Asia
Central/South America
Eastern Europe
Mid East/Africa
North America
Western Europe
Occident



Key Specifications/Special Features:

1. Housing material: LCP 30% G/F 94V-0 black

2. Contact material: phosphor bronze

3. Contact plated: gold 15U" on contact area other 100U" min. lead

4. Current rating: 1 Amp

5. Contact resistance: 30 Mohms

6. Insulator resistance: 1000 Mohms min

7. Dielectric withstanding: AC 500V for 1 minute

8. Operating Temp.: -40 to + 85 deg. C

9. Max processing temp.: 230 deg. C for 30 to 60 seconds

10. Harpoon material: brass

11. Harpoon plated: tin 100U" Min
