SFF 8639 To SFF 8643 Serial Attached SCSI Cable , Black SAS 68 Pin SCSI Cable

China SFF 8639 To SFF 8643 Serial Attached SCSI Cable , Black SAS 68 Pin SCSI Cable supplier
SFF 8639 To SFF 8643 Serial Attached SCSI Cable , Black SAS 68 Pin SCSI Cable supplier SFF 8639 To SFF 8643 Serial Attached SCSI Cable , Black SAS 68 Pin SCSI Cable supplier SFF 8639 To SFF 8643 Serial Attached SCSI Cable , Black SAS 68 Pin SCSI Cable supplier SFF 8639 To SFF 8643 Serial Attached SCSI Cable , Black SAS 68 Pin SCSI Cable supplier

Large Image :  SFF 8639 To SFF 8643 Serial Attached SCSI Cable , Black SAS 68 Pin SCSI Cable

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: SHUANG YI
Certification: ISO9001/ISO14001/SGS/UL/RoHS/Reach
Model Number: SFF-8639 To SFF-8643

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 1.Custom polybag packing 2.Custom paper box packing 3.According to client's request
Delivery Time: 7~10 work days
Payment Terms: T/T, L/C
Supply Ability: 100000 Pieces Per Month
Detailed Product Description
Application: Computer, Server, Power Color: Black PVC Jacket+Blue Aluminum Foil
Conductor: Tinned Cooper With 30awg Connection A: SFF-8643 Male/Mini SAS 36Pin
Connection B: SFF-8639 Mini SAS 68Pin+SATA 15P Wire Size: 30/32 AWG
High Light:

serial attached scsi sas cable

,

sas hard drive cable

SFF 8639 To SFF 8643 Serial Attached SCSI Cable , Black SAS 68 Pin SCSI Cable



Product Description:
30AWG Internal Mini SAS 36pin (SFF-8643 ) Male to SAS 68pin + SATA 15pin Forward Breakout Cable - Black.
Serial Attached SCSI (SAS) is a high-speed data storage interface designed for high-throughput and fast data access. Intended primarily for data storage centers, the SAS interface is backwards compatible with SATA. This allows the user to mix more expensive, lower-capacity SAS drives for applications that require faster data access and higher reliability, with lower-cost, higher-capacity SATA drives for applications with lower access speed requirements. Vision carries a full line of quality SAS cables with connectors for every possible application, both internal and external.

This 1/2 meter long cable uses 30 AWG wires and is intended for internal use. It has a single 36-pin SFF-8087 male Mini-SAS plug with locking latch on one end and has four 68-pin SAS +SATA 15pin plugs on the other, allowing you to connect four SATA drives to an SAS controller. This is a Forward Breakout cable, meaning that it is intended to connect to a host/controller on the SAS end and to drives on the SATA end.

HD Mini SAS 68P+SATA 15P Straight to HD Mini SAS 36P Straight:

1. Series: HD Mini SAS.
2. Cable Length: 1.0 meters.
3. Wire Size: 30AWG, Tinned copper, OD 0. 9*2.3mm.
4. Lock to Mating Part: With Latch.
5. Plating: Au 30u'' min over Ni 100u'' min .
6. Color: Over mold Black.
7. Flammability: Cable Horizontal flame, PCB 94V-0, PBT 94V-0.
8. Environmental Compliance: RoHS.


Features and Benefits:

1. Transmission rate 12 Gbps.

2. Meet SAS3.0 specification.


Mechanical Performance:

1. Mating Force and Unmating Force

2. Condition: EIA 364-13. Insert and extract at a speed of 25mm/minute.

3. Mating Force: 59 N maximum.

4. Unmating Force: 12 N minimum.


Electrical Performance:

1. Contact Resistance

30mohm max. initial, 15mohm maximum after stress test.

2. Dielectric Withstanding Voltage

500 VAC for 1 minute no breakdown.

3. Insulation Resistance

1000 Mega ohms minimum.


Signal Integrity:

1. Mated Connector Impedance: 100 ohm±15%

2. Cable Absolute Impedance: 100 ohm±10%
3. Cable Pair Matching: ±5 ohm
4. Common Mode Impedance: 25 to 40 ohms
5. Insertion loss: -6dB maximum up to 4.5 GHz, 11dB maximum up to 9GHz.
6. Crosstalk: -35 dB up to 6GHz


Advantages:

1. Fully integrated press-fit design of the container, provides a step placement PCB.
2. Multi-port function added to allow or 4 x 8 x cable is mated 1-by-2 or 1-by-4 integrated connector.
3. Integrated container design can be integrated into the radiator, allowing hot solutions long-reach, 4.
4. Passive - and active-copper cable options available, the ability to extend the reach of copper wire and active.
5. 4 x 8 x backshell options and more flexible cable options.
6. Highest-density AOC design, almost double the current density QSFP + AOCs, allows you to choose to use more ports.
7. Cable is in line with SAS-3 (12 gbp s) (system and optical-mode capability), InfiniBand * (10 gbp s), Ethernet (10 gbp s) and other agreements. Meet the next generation as well as many existing industry standards.


Applications:
Data Storage, RAID (Redundant Array of Independent Disks ), Workstations, Rack-mount server, Servers, Storage rack, Solid State Disk.
